| Size | Weight | BB length | Seat post | Seat clamp | Head set |
|---|---|---|---|---|---|
| 440mm-510mm | 1320g/470mm | 68mm | 31.6mm | 34.9mm | 41.2mm |
| Size | MATERIAL | TYPE | TYPE FOR USE | PRICE |
|---|---|---|---|---|
| 700C | Alu 7005 | Road | High Performance | $$$$ |
| SIZE | TT | HT | ST | SA | RC | BB | HA | FL |
|---|---|---|---|---|---|---|---|---|
| 440mm | 505mm | 110mm | 440mm | 75° | 405mm | 70mm | 71° | 367mm |
| 470mm | 520mm | 110mm | 470mm | 74.5° | 405mm | 70mm | 72° | 367mm |
| 500mm | 530mm | 120mm | 500mm | 74° | 405mm | 70mm | 72.5° | 367mm |
| 530mm | 540mm | 135mm | 530mm | 74° | 405mm | 70mm | 73.0° | 367mm |
