Size | Weight | BB length | Seat post | Seat clamp | Head set |
---|---|---|---|---|---|
16"/17"/18" | 1590g/17" | 68mm | 31.6mm | 34.9mm | 44mm |
Size | MATERIAL | TYPE | TYPE FOR USE | PRICE |
---|---|---|---|---|
26" | ALU 7005 | XC | Professional | $$$$ |
SIZE | TT | HT | ST | SA | RC | BB | HA | FL |
---|---|---|---|---|---|---|---|---|
16" | 555mm | 115mm | 406mm | 73.5° | 425mm | 35mm | 70.5° | 460mm |
17" | 565mm | 120mm | 432mm | 73.5° | 425mm | 35mm | 70.5° | 460mm |
18" | 575mm | 125mm | 457mm | 73.5° | 425mm | 35mm | 70.5° | 460mm |
19" | 585mm | 130mm | 483mm | 73.5° | 425mm | 35mm | 70.5° | 460mm |
20" | 595mm | 135mm | 508mm | 73.5° | 425mm | 35mm | 70.5° | 460mm |
